The Birley
campus
Housing unit aligned with the grid
Apartment units forming a grid with the geometry of the site and alignment with the Birley campus
N
The geometry and orientation of my site was an introduction to the structural scheme of the project..
7am
The truss frames span across 1 whole unit of apartment. highlighted in blue therefore holds 2 apartment units.
Pile foundation will be used in order for the structure to be able to bear the load from 4 storeys and allow them to be distributed through the collumn (being the frames) through to the pile cap and equally among the piles.
